Road traffic is of utmost importance; traffic safety is paramount for our travel. Neither the production nor the installation of reflective traffic signs can be taken lightly. When traveling, we should pay close attention to reflective traffic signs and avoid violating traffic regulations. Let’s travel in a civilized and safe manner.
1. Before applying anti-corrosion treatment to the road signs, drilling, punching, and workshop welding of the posts and poles should be completed.
2. Road reflective traffic signs should face the direction of arrival to minimize driver glare.
3. The installation position of the poles and signs should be accurate, and the dimensional and positional errors should be within the specified range. During installation, measures should be taken to prevent damage to the surface anti-corrosion coating.
4. When reflective traffic signs are supported by posts or installed on road structure posts such as traffic lights or cantilever poles, the installation height should be 2000 mm ≤ 2500 mm. When installed in non-pedestrian areas such as median strips or green belts, the installation height should be no less than 1000 mm (new national standard 1200 mm).
5. The installation height of single-column or double-column supported linear induction targets is 1100~1300 mm.
6. When road reflective traffic signs use cantilever support, the installation height should not be less than 5000 mm, taking into account factors that increase road maintenance. When reflective traffic signs use entrance support, the height should be determined according to the road clearing height requirements. Generally, it should be above 5500 mm.
7. The installation spacing between marking plates on the same column should generally not exceed 20 mm. When marking plates are installed on both sides of the column, the lateral spacing is 1 ≤ 3 times the column diameter. When signs are installed on cantilever and column, the installation spacing is not subject to this restriction.
8. The installation angle of road signs should be adjusted according to the horizontal and vertical curves of the road. The vertical axis of signs on level or downhill elevated bridges should be slightly tilted backward.
9. Marking posts should be kept vertical, and their tilt should not exceed 0.5% of the post height, nor should they be allowed to tilt to one side of the lane.
10. The surface of the sign should not be installed within a height range of 6×3m. 10. When setting up roadside signs, they can be at a certain angle to the perpendicular line of the road centerline: 0°~10° for directional and warning signs, and 0°~45° for prohibition signs; signs above the road should be perpendicular to the road centerline, at an angle of 0°~10° to the perpendicular line of the road.
As a strong manufacturer deeply involved in the field of municipal transportation facilities, we mainly produce a full range of products including reflective traffic signs, intelligent traffic lights, and high-strength traffic light poles, meeting the diverse needs of road engineering, municipal construction, and park planning.
Qixiang reflective traffic signs feature clear and eye-catching patterns, are sun-resistant and corrosion-resistant, and have excellent nighttime warning effects; our intelligent traffic lights are equipped with advanced control chips, offering sensitive response and precise switching, suitable for traffic flow management at complex intersections; our traffic light poles are made of high-quality steel, treated with hot-dip galvanizing and powder coating for double rust prevention, making them wind-resistant and pressure-resistant, with an outdoor service life of over 20 years.
Every Qixiang product is made strictly in compliance with national transportation regulations, allowing for customization of features, dimensions, and capabilities. Bulk purchases benefit from factory-direct prices with controlled delivery cycles, and our own production lines guarantee adequate production capacity. With nationwide coverage, a skilled team offers a one-stop shop for everything from solution design to logistics and delivery.
Please follow Qixiang for updates and additional information regarding signage.
